Pump Truck

DXD5356THBL

project

unit

technical   parameters

Chassis and   complete vehicle parameters

chassis

-

North rush   heavy truck

emission   standard

-

Six countries

Engine brand

-

Weichai

Engine   horsepower

PS

460

Bridge number

-

4

wheel base

mm

1950+4650+1350

Total length *   total width * total height

mm

13500*2500*4000

Vehicle   quality

kg

39000

Arm frame and   support leg parameters

Maximum fabric   height

mm

51100

Maximum fabric   radius

mm

45200

Maximum fabric   depth

mm

33900

Arm frame   folding mode

-

RZ

The first arm

length

mm

10600

corner

°

89°

The second arm

length

mm

8750

corner

°

180°

The third arm

length

mm

8450

corner

°

180°

The fourth arm

length

mm

9530

corner

°

235°

The fifth arm

length

mm

6900

corner

°

180°

The sixth arm

length

mm

3500

corner

°

90°

Turn table   rotation Angle

°

359°

Pumping system

Maximum   theoretical pumping capacity

m³/h

140

Maximum export   pressure

Mpa

8.5

The number of   theoretical pumps

Time / minute

25

Hydraulic   system pressure

Mpa

32

The inner   diameter of the conveying cylinder

mm

260

Delivery   cylinder trip

mm

1800

Transmission   pipe diameter

mm

125

Hydraulic oil   cooling mode

-

air patenting

Pumping the   concrete collapse degree

mm

160-220

Maximum   aggregate size

mm

40

Hydraulic   system type

-

open-type   system

Main assembly and brand name

Electrical   control system

-

Spoley

Main oil pump   brand

-

Germany   Rexroth/Push

Branch box   brand

-

Germany   Stiebel/Jie

Arm rack   multichannel valve brand

-

Germany   Hawe/Comay

Gear pump   brand

-

Tianjin   special fine

hydraulic   valve

-

Germany   Rexroth
